Run CAT6 cabling to the displays from the AV equipment location.

#HDMI VIDEO CAPTURE DEVICE UNDER 100 INSTALL#

Install four BG-EXH-50C HDMI extenders by connecting the Transmitters to the Matrix Switcher’s HDMI outputs. The displays located at 100 ft will require HDMI extenders over CAT6 cabling since HDMI cables will not function over 50 ft. Connect the four displays using 40 ft HDMI cables from the Matrix Switcher’s HDMI outputs. Install the BG-UM-88ANS 8-input / 8-output HDMI Matrix Switch for distributing up to eight sources to eight displays.

Some Presentation switchers offer USB-C, USB 2.0/3.0, DisplayPort, and even VGA connections for hosting a variety of devices. These switchers usually have HDMI and wireless connections using technologies like Miracast and Airplay that simplify connectivity. Video Wall Processors are used in airports, sports bars, malls, schools, healthcare facilities, business offices, and residential homes.Ĭonference rooms require video processors in the form of Presentation Switchers ideal for displaying materials transmitted from employees' computers.

But for those interested in digital signage where you’ll rotate displays either vertical and horizontal, most Video Wall Processors will also support layouts like 1x2, 1x3, 2x1, 3x1, and 4x1. There are different types of configurations and layouts including 2x2, 3x3, and 4x4 for entertainment purposes.

#HDMI VIDEO CAPTURE DEVICE UNDER 100 TV#

Video Wall Processors typically accept one source signal for the purpose of displaying it on four TV displays, combined to make one large screen. This device is found in environments like business conference rooms, entertainment venues, restaurants, and schools. There are typically two to six HDMI input connections and one HDMI output for the Display. Multviewers are the way to go if the application requires a video processor showing multiple sources on a single display. They can also be combined with Matrix Switchers to help with costs since Matrix Switchers are more expensive if they require more than eight TV displays. These devices are used in many retail shops, transportation facilities, and malls for advertising and Digital Signage. A common application example would be a Sports Bar, Mall, or anywhere visual imagery can make an impact.Īmplified Splitters are designed to split a single video signal and distribute it to multiple displays, basically duplicating the same image across all displays. These types of switchers can typically scale resolutions and accept audio connections like Digital Coax, SPDIF, and Analog RCA.

#HDMI VIDEO CAPTURE DEVICE UNDER 100 1080P#

The most common device utilized in both commercial and residential applications is a Matrix Switcher capable of delivering 4K and 1080p video from multiple sources to multiple displays. The term “Video Processor” encompasses an array of devices including Matrix Switchers, Amplified Splitters, Multiviewers, Video Walls, and Presentation Switchers. The video sources are typically HDMI, DVI, or VGA being sent from media players, cable boxes, or computers for displaying on TVs or projectors. Video Processors transform video input signals to viewable content.
